If you stack up the orange bars until 1/22, you get 444 cases . Now add up all the grey bars. They add up to ~12,000 cases. So when Wuhan thought it had 444 cases, it had 27 times more. If France thinks it has 1,400 cases, it might well have tens of thousands
The same math applies to Paris. With ~30 cases inside the city, the true number of cases is likely to be in the hundreds, maybe thousands. With 300 cases in the Ile-de-France region, the total cases in the region might already exceed tens of thousands.
Spain and Madrid
Spain has very similar numbers as France (1,200 cases vs. 1,400, and both have 30 deaths). That means the same rules are valid: Spain has probably upwards of 20k true cases already.
In the Comunidad de Madrid region, with 600 official cases and 17 deaths, the true number of cases is likely between 10,000 and 60,000.
If you read these data and tell yourself: “Impossible, this can’t be true ”, just think this: With this number of cases, Wuhan was already in lockdown.
With the number of cases we see today in countries like the US, Spain, France, Iran, Germany, Japan, Netherlands, Denmark, Sweden or Switzerland, Wuhan was already in lockdown.
And if you’re telling yourself: “Well, Hubei is just one region ”, let me remind you that it has nearly 60 million people, bigger than Spain and about the size of France.
2. What Will Happen When These Coronavirus Cases Materialize?
So the coronavirus is already here. It’s hidden, and it’s growing exponentially.
What will happen in our countries when it hits? It’s easy to know, because we already have several places where it’s happening. The best examples are Hubei and Italy.
Fatality Rates
The World Health Organization (WHO) quotes 3.4% as the fatality rate (% people who contract the coronavirus and then die). This number is out of context so let me explain it.
It really depends on the country and the moment: between 0.6% in South Korea and 4.4% in Iran. So what is it? We can use a trick to figure it out.
The two ways you can calculate the fatality rate is Deaths/Total Cases and Death/Closed Cases. The first one is likely to be an underestimate, because lots of open cases can still end up in death. The second is an overestimate, because it’s likely that deaths are closed quicker than recoveries.
What I did was look at how both evolve over time. Both of these numbers will converge to the same result once all cases are closed, so if you project past trends to the future, you can make a guess on what the final fatality rate will be.
This is what you see in the data. China’s fatality rate is now between 3.6% and 6.1%. If you project that in the future, it looks like it converges towards ~3.8%-4%. This is double the current estimate, and 30 times worse than the flu.
It is made up of two completely different realities though: Hubei and the rest of China.
Hubei’s fatality rate will probably converge towards 4.8%. Meanwhile, for the rest of China, it will likely converge to ~0.9%:
I also charted the numbers for Iran, Italy and South Korea, the only countries with enough deaths to make this somewhat relevant.
Iran’s and Italy’s Deaths / Total Cases are both converging towards the 3%-4% range. My guess is their numbers will end up around that figure too.
South Korea is the most interesting example, because these 2 numbers are completely disconnected: deaths / total cases is only 0.6%, but deaths / closed cases is a whopping 48%. My take on it is that a few unique things are happening there. First, they’re testing everybody (with so many open cases, the death rate seems low), and leaving the cases open for longer (so they close cases quickly when the patient is dead). Second, they have a lot of hospital beds (see chart 17.b). There might also be other reasons we don’t know. What is relevant is that deaths/cases has hovered around 0.5% since the beginning, suggesting it will stay there, likely heavily influenced by the healthcare system and crisis management.
The last relevant example is the Diamond Princess cruise: with 706 cases, 6 deaths and 100 recoveries, the fatality rate will be between 1% and 6.5%.
Note that the age distribution in each country will also have an impact: Since mortality is much higher for older people, countries with an aging population like Japan will be harder hit on average than younger countries like Nigeria. There are also weather factors, especially humidity and temperature, but it’s still unclear how this will impact transmission and fatality rates.
This is what you can conclude:
Excluding these, countries that are prepared will see a fatality rate of ~0.5% (South Korea) to 0.9% (rest of China).
Countries that are overwhelmed will have a fatality rate between ~3%-5%
Put in another way: Countries that act fast can reduce the number of deaths by a factor of ten. And that’s just counting the fatality rate. Acting fast also drastically reduces the cases, making this even more of a no-brainer.
Countries that act fast reduce the number of deaths at least by 10x.
So what does a country need to be prepared?
What Will Be the Pressure on the System
Around 20% of cases require hospitalization, 5% of cases require the Intensive Care Unit (ICU), and around 2.5% require very intensive help , with items such as ventilators or ECMO (extra-corporeal oxygenation ).
The problem is that items such as ventilators and ECMO can’t be produced or bought easily. A few years ago, the US had a total of 250 ECMO machines, for example.
So if you suddenly have 100,000 people infected, many of them will want to go get tested. Around 20,000 will require hospitalization, 5,000 will need the ICU, and 1,000 will need machines that we don’t have enough of today. And that’s just with 100,000 cases.
That is without taking into account issues such as masks. A country like the US has only 1% of the masks it needs to cover the needs of its healthcare workers (12M N95, 30M surgical vs. 3.5B needed). If a lot of cases appear at once, there will be masks for only 2 weeks .
Countries like Japan, South Korea, Hong Kong or Singapore, as well as Chinese regions outside of Hubei, have been prepared and given the care that patients need.
But the rest of Western countries are rather going in the direction of Hubei and Italy. So what is happening there?
What an Overwhelmed Healthcare System Looks Like
The stories that happened in Hubei and those in Italy are starting to become eerily similar. Hubei built two hospitals in ten days, but even then, it was completely overwhelmed.
Both complained that patients inundated their hospitals. They had to be taken care of anywhere: in hallways, in waiting rooms…
I heavily recommend this short Twitter thread. It paints a pretty stark picture of Italy today
Medico Humanitas su Facebook: “Situazione drammatica, altro che normale influenza”
Pubblichiamo l’intervento sui social di Daniele Macchini, medico alle Cliniche Humanitas Gavazzeni. Una testimonianza…
bergamo.corriere.it
Healthcare workers spend hours in a single piece of protective gear, because there’s not enough of them. As a result, they can’t leave the infected areas for hours. When they do, they crumble, dehydrated and exhausted. Shifts don’t exist anymore. People are driven back from retirement to cover needs. People who have no idea about nursing are trained overnight to fulfill critical roles. Everybody is on call, always.
Francesca Mangiatordi , an Italian nurse that crumbled in the middle of the war with the Coronavirus
That is, until they become sick. Which happens a lot, because they’re in constant exposure to the virus, without enough protective gear. When that happens, they need to be in quarantine for 14 days, during which they can’t help. Best case scenario, 2 weeks are lost. Worst case, they’re dead.
The worst is in the ICUs, when patients need to share ventilators or ECMOs. These are in fact impossible to share, so the healthcare workers must determine what patient will use it. That really means, which one lives and which one dies.
Coronavirus: ‘We must choose who to treat,’ says Italian doctor
An Italian doctor in Lombardy, a region of Italy that has been quarantined due to the new coronavirus (Covid-19)…
www.brusselstimes.com
“After a few days, we have to choose. […] Not everyone can be intubated. We decide based on age and state of health.” —Christian Salaroli, Italian MD.
Medical workers wear protective suits to attend to people sickened by the novel coronavirus, in the intensive care unit of a designated hospital in Wuhan, China, on Feb. 6. (China Daily/Reuters), via Washington Post
All of this is what drives a system to have a fatality rate of ~4% instead of ~0.5%. If you want your city or your country to be part of the 4%, don’t do anything today.
Satellite images show Behesht Masoumeh cemetery in the Iranian city of Qom. Photograph: ©2020 Maxar Technologies. Via The Guardian and the The New York Times .
3. What Should You Do?
Flatten the Curve
This is a pandemic now. It can’t be eliminated. But what we can do is reduce its impact.
Some countries have been exemplary at this. The best one is Taiwan, which is extremely connected with China and yet still has as of today fewer than 50 cases. This recent paper explain all the measures they took early on, which were focused on containment.
Response to COVID-19 in Taiwan: Big Data Analytics, New Technology, and Proactive Testing
This Viewpoint describes the outbreak response infrastructure developed by the Taiwanese government following the SARS…
jamanetwork.com
They have been able to contain it, but most countries lacked this expertise and didn’t. Now, they’re playing a different game: mitigation. They need to make this virus as inoffensive as possible.
If we reduce the infections as much as possible, our healthcare system will be able to handle cases much better, driving the fatality rate down. And, if we spread this over time, we will reach a point where the rest of society can be vaccinated, eliminating the risk altogether. So our goal is not to eliminate coronavirus contagions. It’s to postpone them.
Source
The more we postpone cases, the better the healthcare system can function, the lower the mortality rate, and the higher the share of the population that will be vaccinated before it gets infected.
How do we flatten the curve?
Social Distancing
There is one very simple thing that we can do and that works: social distancing.
If you go back to the Wuhan graph, you will remember that as soon as there was a lockdown, cases went down. That’s because people didn’t interact with each other, and the virus didn’t spread.
The current scientific consensus is that this virus can be spread within 2 meters (6 feet) if somebody coughs. Otherwise, the droplets fall to the ground and don’t infect you.
The worst infection then becomes through surfaces: The virus survives for up to 9 days on different surfaces such as metal, ceramics and plastics . That means things like doorknobs, tables, or elevator buttons can be terrible infection vectors.
The only way to truly reduce that is with social distancing: Keeping people home as much as possible, for as long as possible until this recedes.
This has already been proven in the past. Namely, in the 1918 flu pandemic.
Learnings from the 1918 Flu Pandemic
You can see how Philadelphia didn’t act quickly, and had a massive peak in death rates. Compare that with St Louis, which did.
Then look at Denver, which enacted measures and then loosened them. They had a double peak, with the 2nd one higher than the first.
If you generalize, this is what you find:
This chart shows, for the 1918 flu in the US, how many more deaths there were per city depending on how fast measures were taken. For example, a city like St Louis took measures 6 days before Pittsburgh, and had less than half the deaths per citizen. On average, taking measures 20 days earlier halved the death rate.
Italy has finally figured this out. They first locked down Lombardy on Sunday, and one day later, on Monday, they realized their mistake and decided they had to lock down the entire country.
Hopefully, we will see results in the coming days. However, it will take one to two weeks to see. Remember the Wuhan graph: there was a delay of 12 days between the moment when the lockdown was announced and the moment when official cases (orange) started going down.
How Can Politicians Contribute to Social Distancing?
The question politicians are asking themselves today is not whether they should do something, but rather what’s the appropriate action to take.
There are several stages to control an epidemic, starting with anticipation and ending with eradication. But it’s too late for most options today. With this level of cases, the two only options politicians have in front of them are containment and mitigation.
Containment
Containment is making sure all the cases are identified, controlled, and isolated. It’s what Singapore, Hong Kong, Japan or Taiwan are doing so well: They very quickly limit people coming in, identify the sick, immediately isolate them, use heavy protective gear to protect their health workers, track all their contacts, quarantine them… This works extremely well when you’re prepared and you do it early on, and don’t need to grind your economy to a halt to make it happen.
I’ve already touted Taiwan’s approach . But China’s is good too. The lengths at which it went to contain the virus are mind-boggling. For example, they had up to 1,800 teams of 5 people each tracking every infected person, everybody they got interacted with, then everybody those people interacted with, and isolating the bunch. That’s how they were able to contain the virus across a billion-people country.
This is not what Western countries have done. And now it’s too late. The recent US announcement that most travel from Europe was banned is a containment measure for a country that has, as of today, 3 times the cases that Hubei had when it shut down, growing exponentially. How can we know if it’s enough? It turns out, we can know by looking at the Wuhan travel ban.
This chart shows the impact that the Wuhan travel ban had delaying the epidemic. The bubble sizes show the number of daily cases. The top line shows the cases if nothing is done. The two other lines show the impact if 40% and 90% of travel is eliminated. This is a model created by epidemiologists , because we can’t know for sure.
If you don’t see much difference, you’re right. It’s very hard to see any change in the development of the epidemic.
Researchers estimate that, all in all, the Wuhan travel ban only delayed the spread in China by 3–5 days .
Now what did researchers think the impact of reducing transmission would be?
The top bloc is the same as the one you’ve seen before. The two other blocks show decreasing transmission rates. If the transmission rate goes down by 25% (through Social Distancing), it flattens the curve and delays the peak by a whole 14 weeks. Lower the transition rate by 50%, and you can’t see the epidemic even starting within a quarter.
The US administration’s ban on European travel is good: It has probably bought us a few hours, maybe a day or two. But not more. It is not enough. It’s containment when what’s needed is mitigation.
Once there are hundreds or thousands of cases growing in the population, preventing more from coming, tracking the existing ones and isolating their contacts isn’t enough anymore. The next level is mitigation.
Mitigation
Mitigation requires heavy social distancing. People need to stop hanging out to drop the transmission rate (R), from the R=~2–3 that the virus follows without measures, to below 1, so that it eventually dies out.
These measures require closing companies, shops, mass transit, schools, enforcing lockdowns… The worse your situation, the worse the social distancing. The earlier you impose heavy measures, the less time you need to keep them, the easier it is to identify brewing cases, and the fewer people get infected.
This is what Wuhan had to do. This is what Italy was forced to accept. Because when the virus is rampant, the only measure is to lock down all the infected areas to stop spreading it at once.
With thousands of official cases — and tens of thousands of true ones — this is what countries like Iran, France, Spain, Germany, Switzerland or the US need to do.
But they’re not doing it.
Some business are working from home, which is fantastic.
Some mass events are being stopped.
Some affected areas are in quarantining themselves.
All these measures will slow down the virus. They will lower the transmission rate from 2.5 to 2.2, maybe 2. But they aren’t enough to get us below 1 for a sustained period of time to stop the epidemic. And if we can’t do that, we need to get it as close to 1 for as long as possible, to flatten the curve .
So the question becomes: What are the tradeoffs we could be making to lower the R? This is the menu that Italy has put in front of all of us:
Nobody can enter or exit lockdown areas, unless there are proven family or work reasons.
Movement inside the areas is to be avoided, unless they are justified for urgent personal or work reasons and can’t be postponed.
People with symptoms (respiratory infection and fever) are “highly recommended” to remain home.
Standard time off for healthcare workers is suspended
Closure of all educational establishments (schools, universities…), gyms, museums, ski stations, cultural and social centers, swimming pools, and theaters.
Bars and restaurants have limited opening times from 6am to 6pm, with at least one meter (~3 feet) distance between people.
All pubs and clubs must close.
All commercial activity must keep a distance of one meter between customers. Those that can’t make it happen must close. Temples can remain open as long as they can guarantee this distance.
Family and friends hospital visits are limited
Work meetings must be postponed. Work from home must be encouraged.
All sports events and competitions, public or private, are canceled. Important events can be held under closed doors.
Then two days later, they added : No, in fact, you need to close all businesses that aren’t crucial. So now we’re closing all commercial activities, offices, cafes and shops. Only transportation, pharmacies, groceries will remain open.”
One approach is to gradually increase measures. Unfortunately, that gives precious time for the virus to spread. If you want to be safe, do it Wuhan style. People might complain now, but they’ll thank you later.
How Can Business Leaders Contribute to Social Distancing?
If you’re a business leader and you want to know what you should do, the best resource for you is Staying Home Club .
Who’s staying home because of COVID-19?
A list of all the companies WFH or events changed because of covid-19
stayinghome.club
It is a list of social distancing policies that have been enacted by US tech companies—so far, 328.
They range from allowed to required Work From Home, and restricted visits, travel, or events.
There are more things that every company must determine, such as what to do with hourly workers, whether to keep the office open or not, how to conduct interviews, what to do with the cafeterias… If you want to know how my company, Course Hero , handled some of these, along with a model announcement to your employees, here is the one my company used (view only version here ).
4. When?
It is very possible that so far you’ve agreed with everything I’ve said, and were just wondering since the beginning when to make each decision. Put in another way, what triggers should we have for each measure.
Risk-Based Model for Triggers
To solve this, I’ve created a model (direct link to copy ).
Coronavirus – When Should You Close Your Office?
How To Use Coronavirus Work From Home Model This model should help you and your company make a decision on whether you…
docs.google.com
It enables you to assess the likely number of cases in your area, the probability that your employees are already infected, how that evolves over time, and how that should tell you whether to remain open.
It tells us things like:
If your company had 100 employees in the Washington state area, which had 11 coronavirus deaths on 3/8, there was a 25% chance at least one of your employees was infected, and you should have closed immediately.
If your company had 250 employees mostly in the South Bay (San Mateo and Santa Clara counties, which together had 22 official cases on 3/8 and the true number was probably at least 54), by 3/9 you would have had ~2% chances to have at least one employee infected, and you should have closed your office too.
[Updated as of 3/12] If your company is in Paris (intramuros), and it has 250 employees, today there’s a 95% chance that one of your employees has the coronavirus , and you should close your office by tomorrow.
The model uses labels such as “company” and “employee”, but the same model can be used for anything else: schools, mass transit… So if you have only 50 employees in Paris, but all of them are going to take the train, coming across thousands of other people, suddenly the likelihood that at least one of them will get infected is much higher and you should close your office immediately.
If you’re still hesitating because nobody is showing symptoms, just realize 26% of contagions happen before there are symptoms .
Are You Part of a Group of Leaders?
This math is selfish. It looks at every company’s risk individually, taking as much risk as we want until the inevitable hammer of the coronavirus closes our offices.
But if you’re part of a league of business leaders or politicians, your calculations are not for just one company, but for the whole. The math becomes: What’s the likelihood that any of our companies is infected? If you’re a group of 50 companies of 250 employees on average, in the SF Bay Area, there’s a 35% chance that at least one of the companies has an employee infected, and 97% chance that will be true next week. I added a tab in the model to play with that.
Conclusion: The Cost of Waiting
It might feel scary to make a decision today, but you shouldn’t think about it this way.
This theoretical model shows different communities: one doesn’t take social distancing measures, one takes them on Day n of an outbreak, the other one on Day n+1. All the numbers are completely fictitious (I chose them to resemble what happened in Hubei, with ~6k daily new cases at the worst). They’re just there to illustrate how important a single day can be in something that grows exponentially. You can see that the one-day delay peaks later and higher, but then daily cases converge to zero.
But what about cumulative cases?
In this theoretical model that resembles loosely Hubei, waiting one more day creates 40% more cases! So, maybe, if the Hubei authorities had declared the lockdown on 1/22 instead of 1/23, they might have reduced the number of cases by a staggering 20k.
And remember, these are just cases. Mortality would be much higher, because not only would there be directly 40% more deaths. There would also be a much higher collapse of the healthcare system, leading to a mortality rate up to 10x higher as we saw before. So a one-day difference in social distancing measures can end exploding the number of deaths in your community by multiplying more cases and higher fatality rate.
This is an exponential threat. Every day counts. When you’re delaying by a single day a decision, you’re not contributing to a few cases maybe. There are probably hundreds or thousands of cases in your community already. Every day that there isn’t social distancing, these cases grow exponentially.
Share the Word
This is probably the one time in the last decade that sharing an article might save lives. They need to understand this to avert a catastrophe. The moment to act is now.
